WT3090 – Digital Infra Red Thermal Imaging Camera (-20℃ to 550℃)

Features:

This product is an infrared camera that integrates surface temperature measurement and real-time thermal image.

The traditional infrared thermometer needs to measure every component one by one while it is not necessary for infrared imaging camera, thus saving time.

The potential problems may be displayed on color display screen clearly.

Moreover, the central point measurement cursor is used to locate quickly and accurately to measure the temperature of the target object.

In order to increase the differentiation, the product is provided with a visible light camera.

The thermal images and visible images are stored in the device and can be read through USB or stored in a computer to generate a report or for print.

With small volume, the product is easy to operate and has strong functionality.

It is the ideal selection for electric power, electronic manufacturing, Industrial inspection and other fields.

The following major functions increase the product’s accuracy and usability:

-The radiation coefficient may be adjusted to increase the measurement accuracy of objects with half reflection surface.

-The highest temperature and lowest temperature cursor may guide the users to the areas with highest and lowest temperature of the thermal images.

-The selectable color palette.

This device is is CE certified as well as SGS certified, so you know you are getting a quality product.

Specifications:

Temperature Range: –20°C to 550°C (–4°F to 842°F)
Temperature Accuracy: ±2℃/±2% (Greater than 300 ℃accuracy is ± 5%)
Emissivity: 0.01 - 1.0
Adjustable Display Screen: 2.8 ″ full angle TFT display screen
Infrared image resolution: 120 x 90
Visible image resolution: 300 000 pixel
LCD resolution: 320 x 240
Shortest focusing distance: 0.5m
Frame rate of thermal images: 9 Hz
Wavelength coverage: 8-14um
Color palette: Spectra, iron oxide red, cold color, black & white, white & black
Storage Capacity: 8G (Approx. 20 thousand image store)
File Format: JPEG
USB: micro USB 2.0 (Includes USB Cable)
Power: Built in Rechargeable Battery (PSU included)
Weight: 323g (Including Battery)
Dimension: 225*70*94mm
Packaging: Hard Case
